Druck DPI610E-Aero Portable Aircraft Leak Tester

The Druck DPI610E-Aero is a low-cost yet flexible portable calibrator for precision leak testing of aircraft pitot static systems. Configured as a single-channel unit for testing either altitude or airspeed parameters, it is fully self-contained with manual pressure and vacuum generation and venting facilities. Conversion to aeronautical units is provided, and the instrument also includes leak and switch tests as well as other functions.

The pneumatics system in the DPI610E-A limits both the maximum rate of climb and descent to protect connected delicate aircraft instrumentation such as Rate of Climb (RoC) meters. With a 5m length aero hose (6mm bore) and RoC meter attached with a total volume of 1 litre the maximum rate of climb is +/-6000 ft/min. Pressure fitting is a choice of AN4, AN6, Hansen or Staubli quick-fit connection which includes an integral valve for letdown to ambient ground pressure conditions.

Features

● Altitude and airspeed leak testing and calibration
● Altitude and airspeed switch testing and calibration
● Altitude and airspeed display for calibration checking
● Integral pressure/vacuum pump
● Accuracy to 11ft and 0.15kts
● Large, task-oriented display
● USB connection for data log transfer
